Model: BM 150/200

Product: Polyethylene (PE) Water Tank

Standard: Manufactured to SIRIM Standard MS 1225:1991

Category: BUMI

Effective Capacity: 150 Gallons

Nominal Capacity: 200 Gallons



External Dimension :-

Top (D1): 1498 mm / 59 inci

Base (D2): 1168 mm / 46 inci

Height (H1): 660 mm / 26 inci

Height (H2): 864 mm / 34 inci

Note:

  • All dimension are rounded-off to the nearest 10 mm (or 0.5 inci)

  • Tank properties subject to change without prior notice

  • Dimension given above are for space required for installation purposes only

  • The manufacturer reserves the right to amend or change the design, patterns and specifications without any prior notice as continuous improvement achieved

  • D1: Diamension of Tank Cover

  • D2: Diamension of Tank Base

  • H1: Height to top of Tank

  • H2: Height to top of Cover

Water

Model: BM 150/200B

Product: Polyethylene (PE) Water Tank

Standard: Manufactured to SIRIM Standard MS 1225:1991

Category: BUMI

Effective Capacity: 150 Gallons

Nominal Capacity: 200B Gallons

External Dimension :-

Top (D1): 1117 mm / 44 inci

Base (D2): 914 mm / 36 inci

Height (H2): 914 mm / 36 inci

Note:

  • All dimension are rounded-off to the nearest 10 mm (or 0.5 inci)

  • Tank properties subject to change without prior notice

  • Dimension given above are for space required for installation purposes only

  • The manufacturer reserves the right to amend or change the design, patterns and specifications without any prior notice as continuous improvement achieved

  • D1: Diamension of Tank Cover

  • D2: Diamension of Tank Base

  • H2: Height to top of Cover

BM 200_250

Model: BM 200/250

Product: Polyethylene (PE) Water Tank

Standard: Manufactured to SIRIM Standard MS 1225:1991

Category: BUMI

Effective Capacity: 200 Gallons

Nominal Capacity: 250 Gallons

External Dimension :-

Top (D1): 1575 mm / 62 inci

Base (D2): 1295 mm / 51 inci

Height (H1): 787 mm / 31 inci

Height (H2): 914 mm / 36 inci

Note:

  • All dimension are rounded-off to the nearest 10 mm (or 0.5 inci)

  • Tank properties subject to change without prior notice

  • Dimension given above are for space required for installation purposes only

  • The manufacturer reserves the right to amend or change the design, patterns and specifications without any prior notice as continuous improvement achieved

  • D1: Diamension of Tank Cover

  • D2: Diamension of Tank Base

  • H1: Height to top of Tank

  • H2: Height to top of Cover

Water

Model: BM 200/250A

Product: Polyethylene (PE) Water Tank

Standard: Manufactured to SIRIM Standard MS 1225:1991

Category: BUMI

Effective Capacity: 200 Gallons

Nominal Capacity: 250A Gallons

External Dimension :-

Top (D1): 1270 mm / 47 inci

Base (D2): 1015 mm / 40 inci

Height (H2): 1320 mm / 52 inci

Note:

  • All dimension are rounded-off to the nearest 10 mm (or 0.5 inci)

  • Tank properties subject to change without prior notice

  • Dimension given above are for space required for installation purposes only

  • The manufacturer reserves the right to amend or change the design, patterns and specifications without any prior notice as continuous improvement achieved

  • D1: Diamension of Tank Cover

  • D2: Diamension of Tank Base

  • H2: Height to top of Cover

BM 250_300 GAL

Model: BM 250/300

Product: Polyethylene (PE) Water Tank

Standard: Manufactured to SIRIM Standard MS 1225:1991

Category: BUMI

Effective Capacity: 250 Gallons

Nominal Capacity: 300 Gallons

External Dimension :-

Top (D1): 1550 mm / 61 inci

Base (D2): 1295 mm / 51 inci

Height (H1): 940 mm / 37 inci

Height (H2): 1067 mm / 42 inci

Note:

  • All dimension are rounded-off to the nearest 10 mm (or 0.5 inci)

  • Tank properties subject to change without prior notice

  • Dimension given above are for space required for installation purposes only

  • The manufacturer reserves the right to amend or change the design, patterns and specifications without any prior notice as continuous improvement achieved

  • D1: Diamension of Tank Cover

  • D2: Diamension of Tank Base

  • H1: Height to top of Tank

  • H2: Height to top of Cover
