SG 200_250 GAL

Model: SG 200/250

Product: Polyethylene (PE) Water Tank

Standard: Manufactured to SIRIM Standard MS 1225:1991

Category: SEGI

Effective Capacity: 200 Gallons

Nominal Capacity: 250 Gallons



External Dimension :-

Top (D1): 1473 mm x 1448 mm / 58 inci x 57 inci

Base (D2): 1194 mm x 1194 mm / 47 inci x 47 inci

Height (H1): 787 mm / 31 inci

Height (H2): 838 mm / 33 inci

Note:

  • All dimension are rounded-off to the nearest 10 mm (or 0.5 inci)

  • Tank properties subject to change without prior notice

  • Dimension given above are for space required for installation purposes only

  • The manufacturer reserves the right to amend or change the design, patterns and specifications without any prior notice as continuous improvement achieved

  • D1: Diamension of Tank Cover

  • D2: Diamension of Tank Base

  • H1: Height to top of Tank

  • H2: Height to top of Cover

SG 250_300 GAL

Model: SG 250/300

Product: Polyethylene (PE) Water Tank

Standard: Manufactured to SIRIM Standard MS 1225:1991

Category: SEGI

Effective Capacity: 250 Gallons

Nominal Capacity: 300 Gallons

External Dimension :-

Top (D1): 1499 mm X 1473 mm / 59 inci x 58 inci

Base (D2): 1219 mm x 1194 mm / 48 inci x 47 inci

Height (H1): 965 mm / 38 inci

Height (H2): 1041 mm / 41 inci

Note:

  • All dimension are rounded-off to the nearest 10 mm (or 0.5 inci)

  • Tank properties subject to change without prior notice

  • Dimension given above are for space required for installation purposes only

  • The manufacturer reserves the right to amend or change the design, patterns and specifications without any prior notice as continuous improvement achieved

  • D1: Diamension of Tank Cover

  • D2: Diamension of Tank Base

  • H1: Height to top of Tank

  • H2: Height to top of Cover

Water

Model: SG 300/400

Product: Polyethylene (PE) Water Tank

Standard: Manufactured to SIRIM Standard MS 1225:1991

Category: SEGI

Effective Capacity: 300 Gallons

Nominal Capacity: 400 Gallons

External Dimension :-

Top (D1): 1524 mm x 1575 mm / 60 inci x 62 inci

Base (D2): 1143 mm x 1143 mm / 45 inci x 45 inci

Height (H1): 1194 mm / 47 inci

Height (H2): 1270 mm / 50 inci

Note:

  • All dimension are rounded-off to the nearest 10 mm (or 0.5 inci)

  • Tank properties subject to change without prior notice

  • Dimension given above are for space required for installation purposes only

  • The manufacturer reserves the right to amend or change the design, patterns and specifications without any prior notice as continuous improvement achieved

  • D1: Diamension of Tank Cover

  • D2: Diamension of Tank Base

  • H1: Height to top of Tank

  • H2: Height to top of Cover
